Catia V5 Beginner to Advanced - Automotive and Industrial by Udemy
Learn Catia V5 from a design engineer with more than 18 years experience in automotive, racing and industrial design
Course Highlights
- Workbenches: Sketcher, Part Design, Assembly Design, Drafting, Generative Shape Design (GSD), Sheetmetal Design and DMU Kinematics (simulations)
- Practice projects to extend your experience fast
- Learn about different industries and how to look for jobs, make your CV and showcase your skills
- Learn to use the software in real job design
- Learn how to think like a professional design engineer
- Learn about the automotive industry and Formula 1
- Learn how to build portfolio for design engineering
Skills you will learn!
Curriculum
10 Topics
A quick about me
Add subtitles in your own language
How was this course designed
Catia V5 workbenches and what you can design
Catia V5 files
Catia V5 general interface
How to modify menus and toolbars
How to use your mouse and keyboard
How to use the STEP files
Watch this - Catia V5 Electrical Harness Design
6 Topics
Let's design the first part
The second part
The final parts
Let's assemble the parts
Let's perform some assembly analysis
Let's create a drawing
14 Topics
Sketcher overview
Point line circle and degrees of freedom
Sketch constraints
Construction elements
Sketch profiles
Exercise 1 - Edit multi-constraints and contact constraints
Sketch operations part 1
Sketch operations part 2 - relimitations
Sketch operations part 3 - transformations
Sketch operations part 4 - project 3D elements
Sketch operations part 5 - project 3D geometry
Exercise 2 - sketch patterns
Sketch analysis
Visualization tools
36 Topics
Pads
Pockets
Sketcher profile rules
Points
Planes
Lines
Exercise 1 - Part Design
Hole
Shaft and groove
Exercise 2 - Part Design
Fillet and chamfer
Exercise 3 - Sketch and Shaft
Shell and thickness
Draft angle
Rib and Slot
Exercise 4 - Sketch and Rib
Multi sections solid and removed multi section
Part body and geometrical sets
Body transformations
Patterns
Boolean operations
3D annotations
Exercise 5 - Part design
Exercise 6 - Part design
Multipad
Multipocket
Thread/Tap
Drafted filleted pad
Drafted filleted pocket
Face-face fillet
Variable edge fillet
Chordal fillet
Tritangent fillet
The stiffner
Solid combine
Exercise 7 - part design
12 Topics
View and render tools
Measurements
Product structure
Assembly manipulation
3D compass
Assembly constraints
Exercise 7 - Assembly Design
Annotations
Clash and section
Enhanced scenes
Search and select
Exercise 8 - Assembly Design
9 Topics
The drafting workbench
Views toolbar
Drawing toolbar
Overload properties
Dimensioning toolbar
Annotations and dress-up
Text replicate
Sheet background - frame and title block
Other useful tools in drafting mode
7 Topics
Lighting and depth
Apply materials
Catalog browser
Performance options
Other Catia V5 tools
Hide multiple elements with a few clicks
Create new custom material
14 Topics
Practice project #1 - Assessing the job that has to be done
Practice project #1 - Planning and collecting information
Practice project #1 - Designing and assembling the parts
Practice project #1 - Product analysis and conclusion
Practice project #2 - Part 1 - Base and bracket
Practice project #2 - Part 2 - The wheel
Practice project #2 - Part 3 - Wire retainer
Practice project #2 - Part 4 - Bulb and wire
Practice project #2 - Part 5 - Rustic lamp assembly
Practice project #3 - Part 1 - Central beam
Practice project #3 - Part 2 - Tow ball mount
Practice project #3 - Part 3 - Brackets
Practice project #3 - Part 4 - Assembly
Practice project #3 - Part 5 - Product analysis
10 Topics
Wireframe and 3D sketches
Points
Lines
Planes
Point and plane repetition
Polyline
Circle and arc
Axis and corner
Spline and connect curve
Helix and spiral
24 Topics
Extrude
Revolve
Fill and join
Split and trim
Sphere
Cylinder
Surfacing exercise #1
Projection of curve on surface
Curve at surface intersection
Offset
Sweep (simple) - part 1
Multi section surface
Blend surfaces
Heal surfaces
Boundary
Convert solid to surface and extract surface from solid
Convert surface body in solid body
Sweep - part two - explicit profile
Sweep - part three - line profile
Sweep - part four - circle profile
Sweep - part five - conic profile
Adaptive sweep
Shape edge and variable fillet
Chordal face-face and tritangent fillet
5 Topics
BIW Junction
BIW Diabolo and holes
BIW Mating flange
BIW bead
BIW blend corner
20 Topics
Sheet Metal Design Introduction
Sheet Metal Parameters K-Factor Neutral Axis and Bend Allowance
Wall and Wall on Edge
Bend Extremities Properties
Swept Walls
Extrusion
Cut Out and Holes
Corner and Chamfer
Fold and Unfold View
Corner Relief
Stamping part 1 - Surface Stamp Bead Curve Stamp and Flanged Cut Out
Stamping part 2 - Louver Bridge Flanged Hole and Circular Stamp
Stiffening Rib
Dowel
User Stamp
Bend and Conical Bend
Bend from Flat Folding and Unfolding
Rolled Walls and Sheetmetal Rolling
Hopper
Patterns and transformation features
15 Topics
Revolute Joint
Cylindrical Joint
Screw Joint
Prismatic Joint
Assembly Constraints Conversion
Gear Joint
Cable Joint
Roll Curve Joint
Planar Joint
Rigid Joint
Point Curve Joint
Curve Slide Joint
Point Surface Joint
Spherical Joint
Simulation - and exercise
7 Topics
Automotive assembly line and vehicle major components
Automotive production process on paper
Applications software and documents used in project development
Automotive assembly line video with comments
Formula one car building
Formula one car major components
Industrial design
5 Topics
Find and design projects by yourself - beginner
Find and design projects by yourself - become a CAD design expert
Practice Project #4 - The Frame
Practice Project #4 - Drawers
Practice Project #4 - Other Features
4 Topics
How to tailor your CV and showcase your experience
How to conduct yourself at an interview
How to build a modern professional portfolio
How to look for a job
